额定载荷Reted capacities (Emax)

5,10,20,30,40,50,75,100,150,200,250,300,500kg

灵敏度 Sensitivity

2.0±0.002  mV/V

精度等级 Accuracy class

±0.02% F.S

零点平衡 Zero balance

±1% F.S

零点温度影响 Temp. effect on zero

±0.02% F.S/10℃

输出温度影响 Temp. effect on Span

±0.02% F.S/10℃

输入阻抗 Input resistance

400±20Ω

输出阻抗 Output resistance

352±3Ω

绝缘电阻 Insulation resistance

≥5000MΩ

温度补偿范围

Temperature range compensated

-10~+40℃

工作温度范围

Operating Temperature Range

-30~+70℃

安全过载 Maximum safe over load

150%F.S

极限过载 Ultimate over load

250%F.S

推荐激励电压

Recommend excitation voltage

10~12V DC

最大激励电压

Maximum excitation voltage

15V DC

密封等级 Sealing Class

IP67

材质 Element material

合金钢Alloy Steel

电缆 Cable

Length：3m
